UGREEN NASync DXP6800 Plus

UGREEN states that its NAS support hot-swapping hard drives, while recommending a shutdown first for data safety

UGOS Pro can build a separate M.2 SSD storage pool on the DXP models that carry M.2 slots, instead of using them only as cache

UGREEN publishes no expansion enclosure for the NASync range; extra hardware goes through the PCIe 4.0 x4 slot instead

UGREEN states 196TB across six 30TB SATA drives and two 8TB M.2 SSDs

Docker is installed from the UGOS Pro App Center and runs containerized apps and services on the NAS

UGOS Pro ships a Virtual Machine Manager, and UGREEN lists virtual machines among the workloads the DXP series runs

UGREEN documents Plex Media Server running through Docker on all DXP series models, with Intel Quick Sync hardware transcoding inside the container; UGOS Pro ships no separate App Center package for it

Surveillance Center handles live view, playback and event detection for IP cameras

Local AI photo tools cover people, object and scene recognition, duplicate detection and custom learning, without uploading photos to the cloud

The published storage modes are JBOD, Basic and RAID 0, 1, 5, 6 and 10, with no flexible mixed-drive mode

UGOS Pro offers Btrfs or EXT4 when a volume is created, and snapshot-based recovery requires Btrfs

UGOS Pro offers only Btrfs and EXT4 at volume creation

UGOS Pro ships a Snapshot app that captures point-in-time versions of files for quick recovery

The Cloud Drives app syncs NAS storage with cloud services for an offsite copy

Sync & Backup backs up Windows and Mac folders to the NAS through the desktop client, and UGOS Pro provides a dedicated Time Machine destination over SMB and Bonjour

UGOS Pro documents no one-touch USB copy app or front-panel button; an attached drive is mounted in Storage Manager and copied by a Sync & Backup task

UGOS Pro sets boot and shutdown schedules from Control Panel > Hardware & Power > Scheduled startup and shutdown

A UPS is connected from Control Panel > Hardware & Power > UPS so the NAS enters standby or shuts down safely; the DXP6800 series works with standard AC UPS units tested by UGREEN, not the US3000 DC model

UGOS Pro supports SMB, FTP, NFS, rsync and WebDAV file protocol services from Control Panel

SAN Manager turns NAS storage into block storage that connected devices mount like a local drive

UGOS Pro lists rsync among its file protocol services, and UGREEN documents backing up to a second NAS or remote server over rsync or WebDAV

Two DDR5 4800 MHz SO-DIMM slots, shipped with 8GB and expandable to 64GB per UGREEN's spec table

UGREEN's spec table lists ODECC (on-die ECC) as supported, which protects the memory chip internally rather than reporting errors to the system

UGREEN states the 10GbE and 2.5GbE ports can be bonded through link aggregation or SMB multichannel to stack their transfer rates

UGREEN documents Wake on LAN on its NAS, woken from the desktop client or mobile app over the local network

One front USB-A 3.2 Gen2 at 10Gb/s, one rear USB-A 3.2 Gen2 and two rear USB 2.0, alongside the two front USB-C Gen2 ports

Two front USB-C 3.2 Gen2 ports at up to 10Gb/s

UGREEN's spec table lists no Thunderbolt port on the DXP6800 Plus; Thunderbolt 4 is reserved for the Pro and Ultra trims

HDMI 2.1 output, listed by UGREEN as up to 4K at 60Hz

Front SD 4.0 card reader

The i3-1215U carries Intel UHD Graphics for 12th Gen processors with Intel Quick Sync Video, which is what drives the 4K HDMI output and Plex transcoding

Intel AES New Instructions are listed as supported on the i3-1215U

The i3-1215U is an Alder Lake-U part with no AI Boost NPU; the local AI photo tools run on the CPU and integrated graphics

UGREENlink is the built-in remote access feature, enabled from Control Panel > Device Connection > Remote access and reached through a custom ug.link address without port forwarding

UGREEN documents DDNS as the advanced alternative to UGREENlink, reaching the NAS through your own domain with router-side port forwarding

The published UGOS Pro app list carries no VPN server, and UGREEN's own remote access guide covers UGREENlink, DDNS and Tailscale, with Tailscale running in Docker and WireGuard left to the user to operate

UGREEN documents enabling SSH from Control Panel > Terminal, with root privileges through sudo
